How to replace your mountain bike fork. Сarbon bike fork
Vložit
- čas přidán 11. 06. 2024
- Install a carbon fork on your bike. Ride in winter and do not ruin your Manitou fork. We use a Toseek carbon fork. Remove the wheel, it will interfere with the removal of the fork. Let's see how the new fork fits on our bike. Seems to be okay. Gaps are good. Carbon fork and carbon stem. Let's start with the stem. Loosen the brake bolts. Loosen the dismounting bolts to separate the stem from our old fork. Be careful now. Usually all steering components start to crumble. Old steerer on open bearings, separator type. Add all the elements of the old steering separately. Remove the old grease. But we have to change the steering because a carbon fork has a carbon shaft. We cannot mount an old steering on a new fork. This one is aluminum, but on the new one the fork has a carbon shaft. The lower ring will not fit. In the new steering bearing of the closed type. The lower cone has a cut. The most important ring with a slot, the only one that fits on a carbon fork. Cut on the side. The lower shell with the bearing fits well. If you use a special tool to remove the old headset, it will just fly out. Do the same with the upper headset. Collect it in a pile and put it aside. We may need it someday. Make sure you grease all the landing surfaces, it is important to grease the lower cup. Let's start cleaning. Apply it to the steering glass on the side of the steering. We always start by hammering a little into the frame, from the bottom and from the top. You have to hit evenly, no distortions! everything should be smooth! Afterwards, when the shells are partially in the frame, we press our our steering wheel with a special tool to make sure everything is correct and even. All is well, everything worked. Our steering is already in our frame. Lubricate the bearings from all sides? upper, lower and upper cones. Slowly, slowly. Put the fork into our frame. The main thing is not to rush and tighten the shirts properly. Put the upper bearing and a cone that clamps the bearing. We put spacers and dust bags at the end. Any grease left on the rod must be removed! We use isopropyl alcohol. It is very important to degrease everything! Here the space of the usual anchor is used for design purposes. Spacer plugs for stem forks to fix the steering. If you tighten it with a 6 mm hex, it will break. Make sure to degrease the inside of the shaft. Isopropyl alcohol and wipes. We put the snack on to test the height of the stem. As you can see, you need a spacer ring. Insert our cork and tighten its hexagon by 6 millimeters. Tighten moderately. The classic anchor comes with a steering wheel. We do not need it, but the cover is used. Then we put on the brake, tighten it. Just in case, tighten the brake disk screws. and tighten the primary wheel. until the tightening is moderate and the sleeve sits exactly in the dropouts. Check The wheel is straight and tight. Align the stem with the wheel. Start tightening. There should be no slippage. There should be no dents in the frame. Apply the front brake and move the steering wheel back and forth. Check from left to right to make sure the steering does not jam, Adjust the brake so that there are no bumps. Done. Carbon fork "toseek" installed on the bike. After replacing the fork, winter riding is possible)
For those who have a love for cycling, this video will be captivating.
This video communicates through mechanics, void of spoken language. Universal appeal regardless of linguistic background. Presented as a DIY video.
#mountainbike #fork #carbon
00:00 How to replace your mountain bike fork.
00:10 Unscrewing the steering wheel of a bike prop.
01:39 Removing the fork from the bicycle.
02:21 Bicycle handlebars.
02:31 Cleaning the handlebars.
03:11 New bicycle handlebars.
04:12 How to press out the lower cup of a bicycle headset.
04:25 How to press out the upper cup of a bicycle headset.
05:12 How to install new bicycle headset cups.
07:32 Installing the carbon fork on your bicycle.
10:28 Installing the brake on your bike's carbon fork.
11:37 Adjusting the handlebars.
🆗🎥🚲
Write in the comments, what you would like me to do in the new video.
❓❔❓
Ask your questions in the comments
👇👇👇 - Věda a technologie
⚠ ❓ ⚠
*ASK YOUR QUESTIONS*
👇👇👇
My new toseek fork got brake caliper not in line with the mount
How can I fix it
Would love to see more of this bike how it rides with that fork.
The bike was returned to its owner. She rides this fork in the winter so as not to spoil the air-oil system.
I saw the mallet being used to put the headset in and I was like oh, must not have it headset press. Seconds later pulls out a headset press.
👍🫡🙋 Moim zdaniem tj. najlepszy kanał o serwisowaniu rowerów w całym YT :) Gratuluję i dziękuję Ci za te filmiki :)
Thanks for the tutorial.
I installed the same fork (I think because it's the same brand), but now when I brake hard the wheel move to the left (brake disc side). Do you have the same issue ?
I notice that In your video, the old fork has a "shoulder" for the axis on the brake disc side like mine... and the new one doesn't have that...
Thank you for your comment. I didn't have any problems with the plug. If you have a badly fixed wheel, try gently going over the places where the wheel axle fits with sandpaper or put washers. Check that the wheel axle is perfectly straight in the fork, sometimes these forks are slightly crooked.
저도 리지드포크로 교체했지요. 아주 좋아요. 가볍고
도움이되어 기쁩니다! 피드백 주셔서 감사합니다! 내 동영상을 친구들과 공유하면 채널 발전에 도움이 될 것입니다! 📈😽
Nice job, well done. How much weight could you reduce? Did you calculate?
The weight has been reduced by 1.1 kg compared to the Manitou fork. The main goal was not to reduce weight, but to provide a fork that can be ridden at sub-zero temperatures without ruining it 😺
1,1kg x 7kg = 7,7kg wagi jeźdźca.
Gdzies w necie znalazłem taki przelicznik. Inny to: 1 kg wagi roweru, jest równoważny 10 kg wagi jeźdźca. Jednak ten przelicznik wydaje mi się zawyżony, więc skłaniam się ku pierwszemu :)
What size is the wheel and fork? I’m a bit confused with the toseek fork sizes as they carry 26,27.5 and 29 but someone said the 26 fork can also accommodate 700c*40 and apparently in your video the fork has lots of room to handle bigger wheels, right?
This fork is for 27.5 wheels, the wheel in the video is also 27.5. It used to fit a wheel with a 700x50 mm tire, but the seat on that bike was very low and there were problems with the cyclist's back. The 26 fork can accommodate 29 wheels, but then the handlebars will be very low.
What's your long term impression of this fork, I've just ordered one for my hybrid
Nice fork, after the race it fell apart)
I went for a ride on it today.)
Share my videos with your friends, it will help the development of the channel!
😘
I have the same fork, does you fork is ok and has no failed?
The owner of the fork is riding and doing well👍
Question, how much weight was dropped or added?
this fork has weight 540 gramms( about 510 gr if shorten)
Też jestem dość pedantyczny w serwisowaniu roweru.
Mam dwie uwagi:
1. tak bym roweru za siodełko żadnego nie wieszał,
2. klamki QR nie zamykałbym równolegle wzdłuż widelca ;)
Bo ciężko potem uchwycić by otworzyć to raz (no dobrze, można paskiem ;) a dwa, istnieje ryzyko zarysowania golenia widelca.
Pozdrawiam 🫡
3:00 Why not use the crown bearing race from the suspension fork?
Because the new headset was sealed bearing?
@@NiceBikeService Great vid ! What sealed bearing kit did you use ? I'm struggling to find one with slotted bottom ring for carbon fork ?
Olá qual graxa vç utiliza?
@@edinaldorodrigues4680 podes usar uma generica eu recomendo a copper da muc off
Porwue una horquilla recta en un cuadro cónico ?
El dueño de la bici tenía una de estas😉 Con el juego adecuado de anillos de columna de dirección, también puedes usar una horquilla de potencia recta, no hay problema
not used tooth paste
😹
